The oscilloscope at top left is being used as XY monitor. Below it is the AX08 Laboratory Peripheral which drives the scope, reads the control switches for the games, and has A/D converter. Below it is the DF32 disk drive. To right is the Straight 8 computer and ASR-33 Teletype.
On the far left is a mechanical adding machine I had on display at the fair.
